STREET CORNER
Looking north along Adriatic Lane
This angle shows the lower eastern volume close to Adriatic Lane and the taller main volume set west behind it. Both begin at natural ground, not on top of the boundary infills.
Share this view
WHERE THE CAMERA WAS
Camera at the southern end of Adriatic Lane, facing about 10 degrees west of north.
Blue shows the approximate camera position and field of view.
Indicative only. The position and viewing angle were estimated from the supplied photograph and marked camera plan.
Check applicant drawing A07
